11QG70120 Hyundai Fuel Filter
First and foremost, the 11QG70120 is a reliable aftermarket Hyundai fuel filter built for heavy-duty diesel equipment. Moreover, this 11QG70120 replacement fuel filter delivers stable protection across construction, marine and generator fleets. In addition, it works perfectly as a cost-effective solution without relying on factory original parts. Therefore, it suits routine maintenance for workshops and large equipment fleets alike. Meanwhile, this guide covers its full specs, working principle and cross-model compatibility clearly.
Core Technical Specifications
To begin with, precise dimensions ensure smooth installation inside standard fuel filter housings. Furthermore, every measurement matches industry mounting standards for direct drop-in replacement:
- Outer Diameter: 111 mm (4.37 inch)
- Inner Diameter: 21 mm (0.83 inch)
- Overall Length: 120 mm (4.72 inch)
- Particle Efficiency: 95% at 30 micron
- Emulsified Water Separation Efficiency: 95%
Besides, these accurate sizes allow quick swap procedures without extra modification work. As a result, maintenance teams can finish filter changes faster on busy job sites.
Working Principle of 11QG70120 Fuel Filter
In general, clean diesel fuel directly protects injectors and engine internal components. Additionally, the 11QG70120 high efficiency fuel filter combines particle trapping and water removal in one integrated design.
Fuel Flow Filtration Process
At first, contaminated diesel enters the filter housing from the fuel supply line. Next, fuel flows through the outer pleated media layer gradually. Then, large solid particles get blocked on the surface structure immediately. After that, fine contaminants down to 30 microns are trapped deep inside the fiber material. Finally, purified fuel moves toward injectors while separated water settles at the bottom chamber naturally.
Particle Contaminant Removal
On one hand, metal debris, rust and dust are intercepted on the outer media surface. On the other hand, tiny fine particles are filtered through multi-layer depth filtration. For this reason, the filter reaches a steady 95% filtration rate for 30‑micron impurities. What is more, the high-capacity pleated design extends service intervals effectively. Consequently, it reduces frequent replacement cycles for long working hours.
Water Separation Performance
Normally, emulsified water inside diesel easily damages fuel systems and shortens engine life. Luckily, this filter features strong water separation ability. In fact, it achieves 95% efficiency for removing emulsified water from low-quality diesel. Hence, it prevents corrosion, injector sticking and unstable engine power in humid environments.
11QG70120 Hyundai Filter Cross Reference Part Numbers
Apart from the Hyundai original part code, this filter matches many global brand cross references. Similarly, it supports universal replacement across different equipment lines:
- ATLAS COPCO: 97054435000
- CLAAS: 687121
- HITACHI: 4724818
- HYUNDAI: 11QG70120
- JOHN DEERE: 811999500
- KOMATSU: 929604D
- RANDON: 218001819
- SANDVIK: BG01458551
- SANY: B222100000729
- SCANIA: 1675795
- SDLG: 11220925
- SUNWARD: 730403010020
- TAMROCK: 56044761
- VOLVO: 14622355
- VOLVO PENTA: 889419
11QG70120 Fuel Filter Full Equipment Compatibility
In particular, this 11QG70120 universal fuel filter fits generators, marine engines, farm machinery and mining equipment worldwide:
CMC Saturne 4800
Himoinsa HRFW 310 T5, HSW 400 CH, HSW 400 INS
Horsch Terra Trac 350
John Deere 6135 RG
Lanmar GRPE Electrogene
Lifter Pramac GSW 325 V
Rivard 300 TC 150, 400 TR 250, 500 TR 250
Sampo Rosenlew SR 2035
Sandvik LH 410
Tecnogen 300 SID
Volvo-Penta Marine TAD 1630
Yamaha Marine Divers
11QG70120 Hyundai Fuel Filter Key Advantages & Maintenance Tips
Above all, this aftermarket filter offers stable performance at a lower operational cost. Firstly, 30-micron filtration protects precision injection parts from abrasive wear. Secondly, high water separation keeps fuel dry even with poor diesel quality. Thirdly, standard sizing enables easy fitting for all listed machine models. In conclusion, it remains a practical choice for long-term fleet and workshop maintenance.
